Delta dore thermostat thermostat tybox 1137 radio- DELTA DORE - 6053064
  • Delta dore thermostat thermostat tybox 1137 radio- DELTA DORE - 6053064

Delta dore thermostat thermostat tybox 1137 radio- DELTA DORE - 6053064

656190
€222.55
Wireless programmable thermostat for boiler or non-reversible heat pump - 2 levels of settings - transmitter + RF receiver Intelligence 5 Years warranty Choice from 2 adjustable temperatures from 5 to 30°C: Comfort, Reduced Daily or weekly programming, which can be customised using a switch Quick selection of operating modes using the selector dial: - On/Off/Auto - Holiday program with built-in calendar Reminder of the annual maintenance service Automatic time change: summer/winter Calibration of the temperature sensor Hourly display of the boiler operating time (excluding DHW) Large backlit screen Can be installed away from the boiler in the most suitable room for taking the temperature, thanks to the wireless technology (150m) lock function Maximises savings thanks to
Quantity

Colissimo Delivery expected from 2026-10-15

Available

Delivery & returns
  • ✓ Free delivery on orders over €79
  • ✓ Free returns within 30 days
Find out more about terms and conditions
Wireless programmable thermostat for boiler or non-reversible heat pump - 2 levels of settings - transmitter + RF receiver Intelligence
5 Years warranty

Choice from 2 adjustable temperatures from 5 to 30°C: Comfort, Reduced
Daily or weekly programming, which can be customised using a switch
Quick selection of operating modes using the selector dial: - On/Off/Auto - Holiday program with built-in calendar
Reminder of the annual maintenance service
Automatic time change: summer/winter
Calibration of the temperature sensor
Hourly display of the boiler operating time (excluding DHW)
Large backlit screen
Can be installed away from the boiler in the most suitable room for taking the temperature, thanks to the wireless technology (150m)
lock function
Maximises savings thanks to the accuracy of the programming, to the nearest ¼ hour, ½ hour or hour
Power supply of the room unit: 2 LR03 batteries (supplied)
Power supply of the receiver: 230 V
Length of the receiver cable: 2 m.
Reversing Dry contact output: 5 A/230V
Radio frequency: 868 MHz
Control range from 5° to 30°C
Regulation base time can be set from 15 minutes to 1 hour¿Control type PI
Protection index : IP 30
Insulation class : Class III

Replaces TYBOX 810 and TYBOX 811RE

Features of product: DELTA DORE THERMOSTAT THERMOSTAT TYBOX 1137 RADIO- DELTA DORE - 6053064

Package Weight (kg)
0.412
Package Height (m)
0.07
Package Width (m)
0.15
Package Length (m)
0.18
Color
Blanc
Dimensions (mm)
H 104 x l 80 x P 35
Garantie
5
Logo Marque
DELTA_DORE
Product type
Thermostat

Delta Dore Thermostats: Reliable Control for Your Heating

A thermostat is not just a simple accessory: it is the device that regulates temperature, comfort stability, and the operational logic of your heating system. When regulation is inaccurate, the consequences are immediate: temperature fluctuations, short generator cycles, unnecessary consumption, and accelerated wear of certain components.

Delta Dore thermostats are designed to ensure stable and consistent regulation suited to the constraints of residential installations, whether it’s a boiler, a heat pump, or a multi-zone system. A compatible part can restore reliable control without modifying the existing installation, as long as the electrical characteristics and type of control are adhered to.

Key Elements for Effective Regulation

Depending on your setup (central heating, pilot wire, dry contact, radio), the components to check or replace may differ. Here are the most critical elements to bring your regulation back to the correct level:

  • Room thermostats (wired or wireless): they measure the temperature and control the generator. In case of drift, erratic display, or unstable regulation, the thermostat is often at fault.

  • Receivers / control modules: they ensure the connection between the thermostat and the equipment (boiler, heat pump, zone). A faulty module can cause inconsistent commands (permanent heating or lack of heating).

  • Probes and sensors: depending on the installations, an indoor or outdoor probe influences regulation. A defective sensor can skew measurement and disrupt heating cycles.

How to Identify the Right Delta Dore Reference?

Many thermostats and receivers look alike, but their technical specifications differ: type of control (dry contact, pilot wire), radio protocol, boiler/heat pump compatibility, power supply, or multi-zone management. A visually similar reference may be functionally incompatible.

To avoid any errors, precisely identify:

  • The exact reference of the thermostat and/or receiver (product label or documentation).

  • The type of installation: boiler, heat pump, single zone or multi-zones.

  • The mode of control: wired, wireless, pilot wire, dry contact.

Technical advice: before replacement, check functional compatibility (type of control, power supply, protocol). Well-suited regulation limits short cycles, stabilizes temperature, and enhances the durability of the installation.
