Elesta mixing valve 3 way type h3mg25 ff1"- E.R.E REGULATION - H3MG25-8
  • Elesta mixing valve 3 way type h3mg25 ff1"- E.R.E REGULATION - H3MG25-8
  • Elesta mixing valve 3 way type h3mg25 ff1"- E.R.E REGULATION - H3MG25-8

Elesta mixing valve 3 way type h3mg25 ff1"- E.R.E REGULATION - H3MG25-8

109203
€84.26

USE The mixing valve provides optimal boiler functioning, and the requested room temperature. The mixing valve can be equipped with actuator. TECHNICAL FEATURES : Max static pressure : 10 bar (1 MPA) Max temperature : 110°C Mini temperature : -30°C DifferentIal pressure drop : 200 kPa CONSTRUCTION Valve body : bronze Axis : brass Washer : PPO Outside plate : Zinc O-ring : EPDM 3 ways valve, brass type M6 controled by motors range 60 50 kW Radiator circuits, 22 kW heating floors, Ø1" KVS 8. Center distance 82mm x Height 105mm

Quantity

Colissimo Delivery expected from 2026-09-24

Available

Delivery & returns
  • ✓ Free delivery on orders over €79 in France
  • ✓ Free returns within 30 days
Find out more about terms and conditions

Features of product: ELESTA MIXING VALVE 3 WAY TYPE H3MG25 FF1"- E.R.E REGULATION - H3MG25-8

Package Weight (kg)
0.89
Package Height (m)
0.1
Package Width (m)
0.115
Package Length (m)
0.14
C
71.5
Ø
F1"
DN
25.0
B
34.5
H
41.0
H1
105
Kv (m³/h)
8.00
Logo Marque
ELESTA
Length (mm)
82.00
PN (bar)
10
Power (details)
22kW / 50kW
Product type
Vanne
